Packing and dispatch technology

storage packing dispatch palletisingIt is crucial an automated packing plant is installed in the process operation without disruption to the plant. That´s why Claudius Peters works closely with the client taking into consideration all aspects of the plant´s operation whatever the application. The Claudius Peters PACPAL packing plant is customized to fit into an existing system; compact and modular it is easily and quickly installed as an integral component. From a standard control technique to a comprehensive automatic dispatch system, Claudius Peters technology provides total control. Clients can record, control and evaluate the production capabilities of individual packing lines with loading alleys (lanes), palletizer´s and material logistics as well as all important plant data.

A typical Claudius Peters PACPAL Packing Plant comprises everything from the bucket elevator, vibrating screen, pre-bin with level indicator, feeding system, packing machine with automatic bag application and empty bag transportation to the bag discharge, transportation and removal system, check weighing, bag rejection, spillage return, dedusting filter and electrical control and automation. The working method of each Claudius Peters PACPAL packing plant is individually tailored to the customers’ requirements; equally the specific properties of the packed materials are of vital importance. Packing plants are either fed via mechanical or via pneumatic conveying systems with a protective screen removing all foreign components. By means of a preceding bin, the material is vented and a constant pre-pressure for controlled material feeding to the packing machine is achieved. After filling the bags, they are distributed via belt conveyors and distribution systems to the dispatch terminal for palletizing or direct truck loading.

Claudius Peters Malaysia also supplies:

  • Clinker cooler up to 13,000 tonnes per day, Claudius Peters’ knowledge and experience of hot clinker handling and processing is unsurpassed. Take for instance our ETA Cooler totally encapsulates the evolution of clinker cooling in one complete system. With its unique transport system, based on the proven ‘moving-floor’ system, this cooler is quick to install and gives users lower operating costs and extremely high reliability.
  • Pneumatic transport. For example, there is the legendary Claudius Peters X Pump and Aeroslide devices that have revolutionized pneumatic conveying and FLUIDCON, a conveyor pipe that offers the advantages of pneumatic conveying, but uses considerably less energy.
  • Silo up to 50,000 tonnes.
  • Loading and unloading.
